export type Dispatcher = {
readContext<T>(
context: ReactContext<T>,
observedBits: void | number | boolean,
): T,
useState<S>(initialState: (() => S) | S): [S, Dispatch<BasicStateAction<S>>],
useReducer<S, I, A>(
reducer: (S, A) => S,
initialArg: I,
init?: (I) => S,
): [S, Dispatch<A>],
useContext<T>(
context: ReactContext<T>,
observedBits: void | number | boolean,
): T,
useRef<T>(initialValue: T): {current: T},
useEffect(
create: () => (() => void) | void,
deps: Array<mixed> | void | null,
): void,
useLayoutEffect(
create: () => (() => void) | void,
deps: Array<mixed> | void | null,
): void,
useCallback<T>(callback: T, deps: Array<mixed> | void | null): T,
useMemo<T>(nextCreate: () => T, deps: Array<mixed> | void | null): T,
useImperativeHandle<T>(
ref: {current: T | null} | ((inst: T | null) => mixed) | null | void,
create: () => T,
deps: Array<mixed> | void | null,
): void,
useDebugValue<T>(value: T, formatterFn: ?(value: T) => mixed): void,
};
在源码中我们可以看到,所有的 hooks 都在这里
首先开始看源码文件 ReactFiberHooks.js,在这里,我们发现了 dispatch 的两个定义
const HooksDispatcherOnMount: Dispatcher = {
readContext,
useCallback: mountCallback,
useContext: readContext,
useEffect: mountEffect,
useImperativeHandle: mountImperativeHandle,
useLayoutEffect: mountLayoutEffect,
useMemo: mountMemo,
useReducer: mountReducer,
useRef: mountRef,
useState: mountState,
useDebugValue: mountDebugValue,
useResponder: createResponderListener,
};
const HooksDispatcherOnUpdate: Dispatcher = {
readContext,
useCallback: updateCallback,
useContext: readContext,
useEffect: updateEffect,
useImperativeHandle: updateImperativeHandle,
useLayoutEffect: updateLayoutEffect,
useMemo: updateMemo,
useReducer: updateReducer,
useRef: updateRef,
useState: updateState,
useDebugValue: updateDebugValue,
useResponder: createResponderListener,
};
一个是首次加载时的 HooksDispatcherOnMount,另一个是更新时的 HooksDispatcherOnUpdate
我们知道,React Fiber 会从 packages/react-reconciler/src/ReactFiberBeginWork.js 开始渲染,里面执行了 beginWork 方法,beginWork 里判断了组件的类型,而我们主要看 FunctionComponent 的渲染,也就是我们要看的 hook
case FunctionComponent: {
const Component = workInProgress.type;
const unresolvedProps = workInProgress.pendingProps;
const resolvedProps =
workInProgress.elementType === Component
? unresolvedProps
: resolveDefaultProps(Component, unresolvedProps);
return updateFunctionComponent(
current,
workInProgress,
Component,
resolvedProps,
renderExpirationTime,
);
}
我们可以看到,在 updateFunctionComponent 方法里,虽然判断了一些条件,但是最终执行的是 renderWithHooks 方法,那么我们就可以从 renderWithHooks 方法开始看,这也是 React Hookd 渲染入口核心函数
export function renderWithHooks(
current: Fiber | null,
workInProgress: Fiber,
Component: any,
props: any,
refOrContext: any,
nextRenderExpirationTime: ExpirationTime,
): any {
renderExpirationTime = nextRenderExpirationTime;
currentlyRenderingFiber = workInProgress;
// 判断是否存在hooks被挂载
// current.memoizedState 指向下一个hooks
nextCurrentHook = current !== null ? current.memoizedState : null;
if (__DEV__) {
hookTypesDev =
current !== null
? ((current._debugHookTypes: any): Array<HookType>)
: null;
hookTypesUpdateIndexDev = -1;
}
if (__DEV__) {
if (nextCurrentHook !== null) {
ReactCurrentDispatcher.current = HooksDispatcherOnUpdateInDEV;
} else if (hookTypesDev !== null) {
ReactCurrentDispatcher.current = HooksDispatcherOnMountWithHookTypesInDEV;
} else {
ReactCurrentDispatcher.current = HooksDispatcherOnMountInDEV;
}
} else {
// 区分是Mount还是Update
ReactCurrentDispatcher.current =
nextCurrentHook === null
? HooksDispatcherOnMount
: HooksDispatcherOnUpdate;
}
// 执行函数,得到对象
let children = Component(props, refOrContext);
if (didScheduleRenderPhaseUpdate) {
do {
didScheduleRenderPhaseUpdate = false;
numberOfReRenders += 1;
// Start over from the beginning of the list
nextCurrentHook = current !== null ? current.memoizedState : null;
nextWorkInProgressHook = firstWorkInProgressHook;
currentHook = null;
workInProgressHook = null;
componentUpdateQueue = null;
if (__DEV__) {
// Also validate hook order for cascading updates.
hookTypesUpdateIndexDev = -1;
}
ReactCurrentDispatcher.current = __DEV__
? HooksDispatcherOnUpdateInDEV
: HooksDispatcherOnUpdate;
children = Component(props, refOrContext);
} while (didScheduleRenderPhaseUpdate);
renderPhaseUpdates = null;
numberOfReRenders = 0;
}
ReactCurrentDispatcher.current = ContextOnlyDispatcher;
const renderedWork: Fiber = (currentlyRenderingFiber: any);
// 重新设置memoizedState, expirationTime等属性
renderedWork.memoizedState = firstWorkInProgressHook;
renderedWork.expirationTime = remainingExpirationTime;
renderedWork.updateQueue = (componentUpdateQueue: any);
renderedWork.effectTag |= sideEffectTag;
if (__DEV__) {
renderedWork._debugHookTypes = hookTypesDev;
}
const didRenderTooFewHooks =
currentHook !== null && currentHook.next !== null;
renderExpirationTime = NoWork;
currentlyRenderingFiber = null;
currentHook = null;
nextCurrentHook = null;
firstWorkInProgressHook = null;
workInProgressHook = null;
nextWorkInProgressHook = null;
if (__DEV__) {
currentHookNameInDev = null;
hookTypesDev = null;
hookTypesUpdateIndexDev = -1;
}
remainingExpirationTime = NoWork;
componentUpdateQueue = null;
sideEffectTag = 0;
invariant(
!didRenderTooFewHooks,
'Rendered fewer hooks than expected. This may be caused by an accidental ' +
'early return statement.',
);
return children;
}
如果 fiber 为空,则认为是首次加载,首次加载,会 ReactCurrentDispatcher.current.useState 将赋值成 HooksDispatcherOnMount.useState,否者赋值 HooksDispatcherOnUpdate.useState。接下来我们先看上面的首次加载的 useState,就是上面提到的 mountState 方法
function mountState<S>(
initialState: (() => S) | S,
): [S, Dispatch<BasicStateAction<S>>] {
// 访问Hook链表的下一个节点,获取到新的Hook对象
const hook = mountWorkInProgressHook();
// 获取初始化state
if (typeof initialState === 'function') {
initialState = initialState();
}
// 存入memoizedState
hook.memoizedState = hook.baseState = initialState;
// 初始化队列
const queue = (hook.queue = {
last: null,
dispatch: null,
lastRenderedReducer: basicStateReducer,
lastRenderedState: (initialState: any),
});
const dispatch: Dispatch<
BasicStateAction<S>,
> = (queue.dispatch = (dispatchAction.bind(
null,
// Flow doesn't know this is non-null, but we do.
((currentlyRenderingFiber: any): Fiber),
queue,
): any));
return [hook.memoizedState, dispatch];
}
我们再来看 mountWorkInProgressHook 方法
function mountWorkInProgressHook(): Hook {
const hook: Hook = {
memoizedState: null,
baseState: null,
queue: null,
baseUpdate: null,
next: null,
};
if (workInProgressHook === null) {
// This is the first hook in the list
firstWorkInProgressHook = workInProgressHook = hook;
} else {
// Append to the end of the list
workInProgressHook = workInProgressHook.next = hook;
}
return workInProgressHook;
}
mountWorkInProgressHook 就是创建一个新的 hook,然后返回 workInProgressHook
我们上面还注意到了,mountState 方法里将当前 fiber 和 queue 绑定到了 dispatchAction 函数上
function dispatchAction<S, A>(
fiber: Fiber,
queue: UpdateQueue<S, A>,
action: A,
) {
invariant(
numberOfReRenders < RE_RENDER_LIMIT,
'Too many re-renders. React limits the number of renders to prevent ' +
'an infinite loop.',
);
if (__DEV__) {
warning(
arguments.length <= 3,
"State updates from the useState() and useReducer() Hooks don't support the " +
'second callback argument. To execute a side effect after ' +
'rendering, declare it in the component body with useEffect().',
);
}
const alternate = fiber.alternate;
if (
fiber === currentlyRenderingFiber ||
(alternate !== null && alternate === currentlyRenderingFiber)
) {
// This is a render phase update. Stash it in a lazily-created map of
// queue -> linked list of updates. After this render pass, we'll restart
// and apply the stashed updates on top of the work-in-progress hook.
didScheduleRenderPhaseUpdate = true;
// 创建一个更新
const update: Update<S, A> = {
expirationTime: renderExpirationTime,
action,
eagerReducer: null,
eagerState: null,
next: null,
};
if (renderPhaseUpdates === null) {
renderPhaseUpdates = new Map();
}
const firstRenderPhaseUpdate = renderPhaseUpdates.get(queue);
if (firstRenderPhaseUpdate === undefined) {
renderPhaseUpdates.set(queue, update);
} else {
// Append the update to the end of the list.
let lastRenderPhaseUpdate = firstRenderPhaseUpdate;
while (lastRenderPhaseUpdate.next !== null) {
lastRenderPhaseUpdate = lastRenderPhaseUpdate.next;
}
lastRenderPhaseUpdate.next = update;
}
} else {
flushPassiveEffects();
const currentTime = requestCurrentTime();
const expirationTime = computeExpirationForFiber(currentTime, fiber);
// 创建一个更新
const update: Update<S, A> = {
expirationTime,
action,
eagerReducer: null,
eagerState: null,
next: null,
};
// Append the update to the end of the list.
const last = queue.last;
// 把当前创建的更新,放入队列的最后
if (last === null) {
// This is the first update. Create a circular list.
update.next = update;
} else {
// 这是一个环, last 的next指向的是first
// 这把更新添加到last的next, update的next又指向first, 重新形成一个环
const first = last.next;
if (first !== null) {
// Still circular.
update.next = first;
}
last.next = update;
}
queue.last = update;
if (
fiber.expirationTime === NoWork &&
(alternate === null || alternate.expirationTime === NoWork)
) {
// The queue is currently empty, which means we can eagerly compute the
// next state before entering the render phase. If the new state is the
// same as the current state, we may be able to bail out entirely.
const lastRenderedReducer = queue.lastRenderedReducer;
if (lastRenderedReducer !== null) {
let prevDispatcher;
if (__DEV__) {
prevDispatcher = ReactCurrentDispatcher.current;
ReactCurrentDispatcher.current = InvalidNestedHooksDispatcherOnUpdateInDEV;
}
try {
const currentState: S = (queue.lastRenderedState: any);
const eagerState = lastRenderedReducer(currentState, action);
// Stash the eagerly computed state, and the reducer used to compute
// it, on the update object. If the reducer hasn't changed by the
// time we enter the render phase, then the eager state can be used
// without calling the reducer again.
update.eagerReducer = lastRenderedReducer;
update.eagerState = eagerState;
if (is(eagerState, currentState)) {
// Fast path. We can bail out without scheduling React to re-render.
// It's still possible that we'll need to rebase this update later,
// if the component re-renders for a different reason and by that
// time the reducer has changed.
return;
}
} catch (error) {
// Suppress the error. It will throw again in the render phase.
} finally {
if (__DEV__) {
ReactCurrentDispatcher.current = prevDispatcher;
}
}
}
}
if (__DEV__) {
if (shouldWarnForUnbatchedSetState === true) {
warnIfNotCurrentlyBatchingInDev(fiber);
}
}
// 最后执行一个调度
scheduleWork(fiber, expirationTime);
}
}
这里主要做的就是将 fiber 更新形成一个闭环,将所有更新过程产生的更新记录在 renderPhaseUpdates 这个 Map 上,我们发现最后又调用了 scheduleWork,scheduleWork 这里不说了,前面有详细的说明,scheduleWork 主要用于更新任务
function updateState<S>(
initialState: (() => S) | S,
): [S, Dispatch<BasicStateAction<S>>] {
return updateReducer(basicStateReducer, (initialState: any));
}
我们可以看到,updateState 最终调用的是 updateReducer,updateReducer 方法里传入了 basicStateReducer,basicStateReducer 是直接返回 action 的值,如果是函数,还会帮忙执行以下
function updateReducer<S, I, A>(
reducer: (S, A) => S,
initialArg: I,
init?: I => S,
): [S, Dispatch<A>] {
const hook = updateWorkInProgressHook();
const queue = hook.queue;
invariant(
queue !== null,
'Should have a queue. This is likely a bug in React. Please file an issue.',
);
queue.lastRenderedReducer = reducer;
// 开始渲染更新
if (numberOfReRenders > 0) {
// This is a re-render. Apply the new render phase updates to the previous
// work-in-progress hook.
const dispatch: Dispatch<A> = (queue.dispatch: any);
if (renderPhaseUpdates !== null) {
// Render phase updates are stored in a map of queue -> linked list
// 获取quene
const firstRenderPhaseUpdate = renderPhaseUpdates.get(queue);
if (firstRenderPhaseUpdate !== undefined) {
renderPhaseUpdates.delete(queue);
let newState = hook.memoizedState;
let update = firstRenderPhaseUpdate;
do {
// Process this render phase update. We don't have to check the
// priority because it will always be the same as the current
// render's.
const action = update.action;
// 执行reducer,得到新的 state
newState = reducer(newState, action);
// 继续
update = update.next;
} while (update !== null);
// Mark that the fiber performed work, but only if the new state is
// different from the current state.
if (!is(newState, hook.memoizedState)) {
markWorkInProgressReceivedUpdate();
}
// 更新memoizedState的值
hook.memoizedState = newState;
// Don't persist the state accumlated from the render phase updates to
// the base state unless the queue is empty.
// TODO: Not sure if this is the desired semantics, but it's what we
// do for gDSFP. I can't remember why.
if (hook.baseUpdate === queue.last) {
hook.baseState = newState;
}
queue.lastRenderedState = newState;
// 返回新值了
return [newState, dispatch];
}
}
// 没有更新,返回存储的memoizedState
return [hook.memoizedState, dispatch];
}
我们可以看到,一进来,就开始获取 renderPhaseUpdates 上的更新记录,也就是更新队列
updateReducer 方法里执行 reducer 一次之后,将 update 又赋值为 update.next,这样做就是为了保证 reducer 的是最新的值
我们再接着看一进来是如何获取 hook 的
function updateWorkInProgressHook(): Hook {
// This function is used both for updates and for re-renders triggered by a
// render phase update. It assumes there is either a current hook we can
// clone, or a work-in-progress hook from a previous render pass that we can
// use as a base. When we reach the end of the base list, we must switch to
// the dispatcher used for mounts.
if (nextWorkInProgressHook !== null) {
// There's already a work-in-progress. Reuse it.
workInProgressHook = nextWorkInProgressHook;
nextWorkInProgressHook = workInProgressHook.next;
currentHook = nextCurrentHook;
nextCurrentHook = currentHook !== null ? currentHook.next : null;
} else {
// Clone from the current hook.
invariant(
nextCurrentHook !== null,
'Rendered more hooks than during the previous render.',
);
currentHook = nextCurrentHook;
const newHook: Hook = {
memoizedState: currentHook.memoizedState,
baseState: currentHook.baseState,
queue: currentHook.queue,
baseUpdate: currentHook.baseUpdate,
next: null,
};
if (workInProgressHook === null) {
// This is the first hook in the list.
workInProgressHook = firstWorkInProgressHook = newHook;
} else {
// Append to the end of the list.
workInProgressHook = workInProgressHook.next = newHook;
}
nextCurrentHook = currentHook.next;
}
return workInProgressHook;
}
我们可以看到,获取当前执行 hook,就是我们上面看到的 workInProgressHook,这里判断了是否还有重新更新的 state,如果有,继续处理 workInProgressHook,到这里就结束了
最后,附上神图,这个 hooks 源码,自己第一次看并没有看懂,所以在掘金上找到了一个大牛的神图,看了以后会顺利走下来
